Machine Package Includes:
- Model STS-1 Sub. Assembly
- Integrated Guard
- Motor Assembly
- Wrench Kit
- Carrying Case
- Operators Manual
| Technical Specifications |
| Property |
Inches |
Metric |
| OD Mounting: |
*.125″ – 1.125″ |
*(3.2 mm – 28.6 mm) |
| Wall Thickness (max): |
.125″ |
(3.2 mm) |
| Axial clamping length (min): |
*.190″ |
*(4.8 mm) |
| Axial Feed Travel: |
.200″ |
(5.1 mm) |
Weight:
110V/220 Corded
Cordless |
8.7 lbs
7.3 lbs |
(4.0 kg)
(3.3 kg) |
| Cutting Head Toolbit slots: |
1 |
|
| Height over motor: |
11.900” |
(302.3 mm) |
| Machine Width: |
3.100” |
(78.7 mm) |
| Length over motor |
10.900″ |
(276.9 mm) |
| Minimum Electric Power |
7.2A@100V 50/60hz
9.6A@110V 50/60hz
4.8A@220V 50/60hz |
|
*With optional accessory included
Operating Manual: STS-1 w/ Cordless or Corded Motor
Technical Specifications: STS-1 w/ Cordless or Corded Motor
Brochure: STS-1
Quick Start Guide
| Optional Accessories |
| Property |
Inches |
Metric |
| Bench Stand Assembly |
|
|
| Saddles |
|
|
| Battery Charger |
|
|
| Batteries |
|
|
|
|
|
