224B

The extremely rugged and dependable Model 224B BEVELMASTER™ portable ID mount pipe beveling machine tool is ideal for beveling, facing and/or counterboring on larger pipe. The tool is configured with an in-line feed knob and two-speed pneumatic drive motor at a right angle to the lathe head. The Model 224B System pipe beveling machine comes complete with (3) tool holder assemblies, mandrel assemblies, mandrel head assemblies (3 jaws), upper lifting frame (floor stand available as an option), pneumatic motor assembly wrench kit and operator’s manual. This is the new standard of precision in larger diameter beveling.

Pipe/Tube Size:	6.813″ – 42.000″ (173.0 mm – 1066.8 mm)
Wall Thickness:	**2.340″ (59.4 mm) max
Drive Options:	Air Hydraulic

Machine Package Includes:

Model 224B Sub. Assembly
Tool Holder Assembly
Drive Motor Assembly
Mandrel Assembly
Mandrel Head Assembly, 3 Jaw
Lathe Lifting Frame Assembly
Jaw Block Set
Foot Pedal Assembly
Wrench Kit
Operators Manual

Property	Inches	Metric
Technical Specifications
ID Mounting: Standard Mandrel Extension Kit (option)	6.813″ – 24.630″ 24.530″ – *42.000″	(173.1 mm – 625.6 mm) (623.1 mm – 1066.8 mm)
OD Machining (max): Standard Single Point Accessory (option) – Beveling Single Point Accessory (option) – Flange Facing	24.000″ 42.000″ 50.000″	(609.6 mm) (1066.8 mm) (1270.0 mm)
Counterboring:	8.500″ – 24.000″	(216.0 mm- 609.6 mm)
Wall Thickness: Standard Form Tool Single Point Insert	2.340″ 5.000	(59.4 mm) (127.0 mm)
Axial Feed Travel:	5.380″	(136.7 mm)
Feed Rate: (Per Revolution)	.083″	(2.1 mm)
Weight:	420 lbs	(190 kg)
Cutting Head Toolbit slots:	***3
Rotating head diameter: Standard Single Point Accessory (option)	27.000″ 60.780″	(685.8 mm) (1543.8 mm)
Length over machine:	39.750″	(1009.7 mm)
Minimum Air Power requirement:	95 cfm 90 psi	(44.8 L/s) (621 kPa)
Minimum Hydraulic Power requirement:	3 gpm – 15 gpm @ 1500 psi 15 gpm – 20 gpm @ 1000 psi	(.19 L/s – .94 L/s) @ 10342 kPa (.94 L/s – 1.265 L/s) @ 6894 kPa

*With optional accessory included

**For larger wall thickness, contact Tri Tool Inc. for heavier wall procedures

*** 1 Toolbit when using single point kit

Documents

Operating Manual: 224B
Technical Specifications: 224B w/ Air Or Hydraulic Motor

Property	Inches	Metric
Optional Accessories
Single Point Module Kit
ID Tracking Module Kit
Full Function Miter Mandrel
Full Function Miter Mandrel Extension Kit
Jaw Block Extension Kit	24.530″ – 42.000″	(623.1 mm – 1066.8 mm)
Floor Stand
Spring Hanger Assembly
Air Caddy (Filter Regulator Lubricator)
